Evaluation Board for 89HP0508P Repeater, 16-lane, 5Gbps, PCIe2
The 89HP0508P Repeater Evaluation Board is designed to enable quick in-system testing of Renesas’s 8-channel, 5Gbps, PCIe 2.1 Repeater IC product.
This board...
Featured Documents:
Overview
Description
The IDT 89HP0508P 8-channel PCIe Gen2 Repeater offers the industry a blend of top analog performance, lower power, and the most system level features in signal repeaters optimized for demanding 2.5Gbps to 5Gbps applications in computing, storage, and communications.
Features
- 8 channel PCIe Gen2 Signal Repeater
- Advanced signal conditioning features
- Advanced diagnostic features
- Advanced power saving features
- Built-in mux/demux for Fail-Over support
- I2C programming interface
- Commercial and Industrial temperature
Comparison
Applications
Design & Development
Software & Tools
Boards & Kits
Models
ECAD Models
Schematic symbols, PCB footprints, and 3D CAD models from SamacSys can be found by clicking on products in the Product Options table. If a symbol or model isn't available, it can be requested directly from the website.
Processing table
| CABGA | 100 | C | No | Tray | 3 | ||
| CABGA | 100 | C | No | Reel | 3 | ||
| CABGA | 100 | C | Yes | Tray | 3 | ||
| CABGA | 100 | C | Yes | Reel | 3 | ||
| CABGA | 100 | I | Yes | Tray | 3 | ||
| CABGA | 100 | I | Yes | Reel | 3 | ||
| CABGA | 100 | I | No | Tray | 3 | ||
| CABGA | 100 | I | No | Reel | 3 |
