Overview
Description
2.5V Wide Range Frequency DDR1 Clock Driver (45MHz - 233MHz)
Features
- Low skew, low jitter PLL clock driver
- 1 to 10 differential clock distribution (SSTL_2)
- Feedback pins for input to output synchronization
- PD# for power management
- Spread Spectrum-tolerant inputs
- Auto PD when input signal removed
- Choice of static phase offset available, for easy board tuning
Comparison
Applications
Design & Development
Models
ECAD Models
Schematic symbols, PCB footprints, and 3D CAD models from SamacSys can be found by clicking on products in the Product Options table. If a symbol or model isn't available, it can be requested directly from the website.
Processing table
Pkg. Type |
Lead Count (#) |
Temp. Grade |
Pb (Lead) Free |
Carrier Type |
Buy / Sample |
|
|---|---|---|---|---|---|---|
| Part Number | ||||||
| TSSOP | 48 | C | No | Tube | ||
| TSSOP | 48 | I | Yes | Tube | ||
| TSSOP | 48 | I | Yes | Reel | ||
| TSSOP | 48 | C | Yes | Tube | ||
| TSSOP | 48 | C | Yes | Reel | ||
| TSSOP | 48 | C | Yes | Tube | ||
| TSSOP | 48 | C | Yes | Reel | ||
| TSSOP | 48 | C | No | Reel | ||
| CABGA | 56 | C | No | Tray | ||
| CABGA | 56 | C | Yes | Tray | ||
| CABGA | 56 | C | Yes | Reel | ||
| CABGA | 56 | C | No | Reel | ||
| VFQFPN | 40 | C | No | Tray | ||
| VFQFPN | 40 | C | Yes | Tray | ||
| VFQFPN | 40 | C | Yes | Reel | ||
| VFQFPN | 40 | C | No | Reel | ||
| TVSOP | 48 | C | No | Tube | ||
| TVSOP | 48 | C | Yes | Tube | ||
| TVSOP | 48 | C | Yes | Reel | ||
| TVSOP | 48 | C | No | Reel |
