Overview

The CA91L862A (QSpan II) is a PCI-to-Host processor bridge for the Freescale PowerQUICC (MPC860/850/821), the QUICC (MC68360), and the MC68040 processors. The QSpan II operates at speeds up to 50 MHz on the processor bus, with programmable parity and burst/prefetch capability. It provides 32-bit / 33 MHz PCI 2.2 support for embedded processor applications.

CA91L862A - Block Diagram
CA91L862A - Block Diagram
  • Operates up to 50 MHz on the processor bus
  • Integrated PCI bus arbiter
  • CompactPCI Hot Swap Friendly
  • Serial EEPROM interface for Plug and Play compatibility on PCI
  • Universal PCI signaling (3.3V and 5V compliant)
  • High-performance DMA controller with support for Direct and Linked List modes
  • Mailbox registers for passing parameters between host and embedded environments

Documentation

Design & Development

ECAD Models

Schematic symbols, PCB footprints, and 3D CAD models from SamacSys can be found by clicking on products in the Product Options table. If a symbol or model isn't available, it can be requested directly from the website.

Explore ECAD Models
Diagram of ECAD Models

Product Options

    Processing table
    Pkg. Type
    Carrier Type
    Moisture Sensitivity Level (MSL)
    Price (USD) | 1ku
    Buy / Sample
    Part Number
    CA91L862A-50IE
    circleActive
    memory
    view_in_ar
    Samples Available
    		 PBGA Tray 3 70.35 Get Samples,
    CA91L862A-50IEV
    circleActive
    memory
    view_in_ar
    Samples Available
    		 PBGA Tray 3 Get Samples,
