R9A06G150 ASSP EASY Voice HMI Kit
The ASSP EASY Voice HMI Kit is based on the R9A06G150 RISC-V ASSP. It is an edge voice recognition development kit designed to be used by ecosystem partners,...
Featured Documents:
Overview
Description
The R9A06G150 RISC-V MCU ASSP is specifically optimized for voice and sound triggered human machine interfaces. Alongside ecosystem partners, this provides a complete, production-ready keyword spotting and recognition system solution. With 100 MHz performance, 256/128/16 KB of Flash/RAM/DataFlash memory, advanced digital and analog microphone input and playback interfaces, small package, and memory expansion options, the R9A06G150 provides the foundation for a turnkey voice HMI solution including Renesas specialized partners' software.
The chip is manufactured by Renesas and pre-programmed at the factory with specialized application code developed by IDHs (independent design houses), third parties with demonstrated specialized expertise in the development and integration of keyword spotting and voice driven user interfaces with proven customer support capability, to bring the projects to completion and secure the successful transition to the mass-production stage. The strongly collaborative solution with the IDH is fundamental value proposition and the key to success. The end-product is composed of the combination of Renesas hardware and third-party software.
Features
- Enabling innovative voice command HMI
- 100MHz CPU with DSP instructions, floating-point extension and cost optimized specification
- Specialized audio PDM & SSI I/F for seamless connection to state-of-the-art microphones and codecs. Compatible with low-cost analog microphones and outputs.
- Low power consumption by optimal mix of lowest active current, reduced standby current, background operation, SRAM power-off choices, fast wakeup, low power timers.
- Controlled by external host I/F via SCI/UART, SPI, I3C or I2C
- Small package support for cost and integration effectiveness (QFN 48, 32, 24).
- 256KB program flash / 128KB RAM memory, 16KB data flash
- QSPI interface for easy memory expansion
- Shortest time to market with pre-developed software
- Customizable parameters & application options
- Supported by easy-to-use PC GUIs/configuration tools
- Controlled by external host I/F
- Complete reference design: hardware, software, kit, tools, hardware datasheet, software datasheet, GUI manual, app notes
- Add voice control functionality with cost effective solution
- Avoid upfront toolchain investment
- No specialty expertise required
- Production-ready solution software and hardware
Comparison
Applications
- Home/Building Automation
- Consumer
- Healthcare
- Interactive toys
- Intelligent mirrors and displays
- Home appliances such as air conditioners, heating systems, lighting control, access controls
Documentation
Featured Documentation
Log in required to subscribe
|
|
|
|
|---|---|---|
| Type | Title | Date |
| Datasheet | PDF 1.47 MB | |
| Product Brief | PDF 312 KB 日本語 | |
| Flyer | PDF 407 KB | |
| Other | PDF 10.28 MB 日本語 , 简体中文 | |
| General Reliability Literature | PDF 14.70 MB 日本語 | |
|
5 items
|
||
Design & Development
Boards & Kits
Models
ECAD Models
Schematic symbols, PCB footprints, and 3D CAD models from SamacSys can be found by clicking on products in the Product Options table. If a symbol or model isn't available, it can be requested directly from the website.
Processing table
| 256 | 128 | -40 to +85°C | HWQFN | 48 | 7 x 7 x 0.8 | 0.5 | ||
| 256 | 128 | -40 to +85°C | HWQFN | 32 | 5 x 5 x 0.8 | 0.5 | ||
| 256 | 128 | -40 to +85°C | HWQFN | 24 | 4 x 4 x 0.8 | 0.5 |
Tips for Using This Parametric Table:
- Hide Filters button in header: Collapse or expands filters
- Column sort buttons in header: Sort Column alphabetically / numerically descending or ascending
- Reset button in header: Reset all filters to the page default
- Full Screen button in header: Expand the table to full screen view (user must close out of full screen before they can interact with rest of page)
- Export button in header: Export the filtered results of the table to an Excel document
- Filter parts search bar in header: Type to filter table results by part number
- Hide column button in column headers: Select to hide columns in table
- AND / OR toggle switches in header: Toggles the logic of this particular filter to be “AND” or “OR” logic for filtering results
- Multiselect checkboxes at beginning of each row in table: Select these checkboxes to compare products against each other
- Document icon next to product name in row: View the featured document for this product
- Chip icon next to the right of the document icon in row: View the block diagram for this product
- Cart icon to the right of the chip icon: Indicates that samples are available for this product
Videos & Training
RISC-V ASSP EASY MCU for Voice HMI
An overview of the RISC-V ASSP, specifically optimized for voice controlled human machine interface systems. Alongside ecosystem partners, this provides a complete, production-ready voice control systems. Visit the RISC-V ASSP page for more details.
