Overview

The SLG59M1606V dual N-channel load switch is designed for load switching applications. The part comes with two 4.5A-rated MOSFETs switched on by two ON control pins. The turn-on time for each MOSFET is independently adjusted by an external capacitor.

SLG59M1606V Diagram
SLG59M1606V Diagram
  • Optimized for high-current point-of-load applications
  • Power supply: 2.5V ≤ VDD ≤ 5.5V
  • Input voltage range: 0.85V ≤ VD ≤ VDD
  • 16mΩ RDSON while supporting 4.5A
  • Output voltage slew-rate control by an external capacitor
  • Over-temperature protection

Applications

  • Ideal for switching ON and OFF S0 +5.0 and 3.3V power rails with associated support circuitry
  • Ideal for switching ON and OFF power rails 5.5V or less
  • Can use either channel up to 4.5A with a combined maximum current of 8.5A
  • Maximum load capacitance of 1000μF for each Channel Source terminal

Documentation

= Featured Documentation
Type Title Date
Datasheet
SLG59M1606V Datasheet
PDF 250 KB
Guide
GreenFET Product Selection Guide
PDF 2.76 MB
Brochure
GreenFET Robust Load Switches
PDF 5.06 MB
Application Note
AN-CM-272 Extending the GreenFET Load Switch Maximum Operating Current
PDF 911 KB
Other
SLG59M1606V Layout Guide
PDF 282 KB
5 items

Design & Development

Software Downloads
Type Title Date
PCB Design Files
GreenFET Altium Library
ZIP 65 KB
PCB Design Files
GreenFET Eagle Library
ZIP 9 KB
PCB Design Files
GreenFET OrCAD Library
ZIP 221 KB
PCB Design Files
High Voltage GreenFET Altium Library
ZIP 23 KB
PCB Design Files
High Voltage GreenFET Eagle Library
ZIP 2 KB
PCB Design Files
High Voltage GreenFET OrCAD Library
ZIP 61 KB
6 items
SLG59M1606V-EVB

SLG59M1606V-EVB

Evaluation
Learn More

SLG59M1606V Evaluation Board

The SLG59M1606V-EVB board evaluates the SLG59M1606V GreenFET, Dual N-Channel Load Switch.
