Overview
Description
Provides 12 PCIe Gen2 lanes and 12 ports of high-performance, deterministic system interconnect switching. All ports receive full line rate, non-blocking throughput for multiple traffic flows regardless of switch loading.
Features
- 12 PCIe Gen2 Lanes, 12 Switch Ports
- Non-blocking switch architecture optimized for High Performance System Interconnect
- Partionable switch architecture for true multi-root support
- Multiple Nontransparent Bridging functions supported (NTB)
- Movable upstream support
- On-board DMA support
- Internal buffering and flow control credits optimized for maximum bandwidth and large payloads
- Low latency, Low power
Comparison
Applications
Design & Development
Software & Tools
Models
ECAD Models
Schematic symbols, PCB footprints, and 3D CAD models from SamacSys can be found by clicking on products in the Product Options table. If a symbol or model isn't available, it can be requested directly from the website.
Processing table
Pkg. Type |
Lead Count (#) |
Temp. Grade |
Pb (Lead) Free |
Carrier Type |
Buy / Sample |
|
|---|---|---|---|---|---|---|
| Part Number | ||||||
| FCBGA | 324 | C | No | Tray | ||
| FCBGA | 324 | C | No | Reel | ||
| FCBGA | 324 | C | Yes | Tray | ||
| FCBGA | 324 | C | Yes | Reel | ||
| FCBGA | 324 | I | Yes | Tray | ||
| FCBGA | 324 | I | Yes | Reel | ||
| FCBGA | 324 | I | No | Tray | ||
| FCBGA | 324 | I | No | Reel | ||
| FCBGA | 324 | C | No | Tray | ||
| FCBGA | 324 | C | No | Reel | ||
| FCBGA | 324 | C | Yes | Tray | ||
| FCBGA | 324 | C | Yes | Reel | ||
| FCBGA | 324 | I | Yes | Tray | ||
| FCBGA | 324 | I | Yes | Reel | ||
| FCBGA | 324 | I | No | Tray | ||
| FCBGA | 324 | I | No | Reel |
