Title Information
Pkg. Name
Name used to describe Renesas packages.
 L32.5X7A
Pkg. Previous Code
Package code maintained as part of the Renesas and Intersil merger.
 LVW
Package Status
 Active
Package Type
 QFN
Class
 PLASTIC
Package Code
The unique identifier of this package.
 LVW
Lead Count
 32
Pb (Lead) Free
 Yes
Length
 7.01mm
Width
 5mm
Thickness
Seated height or Package height
(Please check the outline drawing)
 1mm
Pkg. Dimensions (mm)
Package Dimensions. Example: 5 x 7 x 0.5
 7.01 x 5.00 x 1.00

Documentation
Type Title Date
Package Outline Drawing
l32.5x7a: 32 Lead Quad Flat No-Lead Plastic Package
PDF 73 KB
1 item
