Overview

The ISL28133EVAL1Z evaluation board is configured as a precision high-gain (G = 10,000) differential amplifier and demonstrates the level of performance possible with this type of amplifier while operating from battery voltages as low as 2.4V.

The ISL28133 chopper stabilized rail-to-rail op amp features a low 8µV maximum VOS over-temperature and a 0.1Hz 1/f noise corner frequency enabling very high gain single-stage DC amplifiers that can operate from single cell batteries while consuming only 20µA of current.

ISL28133EVAL1Z RRIO Chopper Op Amp Eval Board
ISL28133EVAL1Z RRIO Chopper Op Amp Eval Board
  • Operates from a single supply, +2.4VDC to +5.5VDC or from split supplies, ±1.2VDC to ±2.75V
  • Configured for a single op amp connected for single-ended or differential input with closed loop gain of 10,000
  • Single external reference voltage (VREF) pin and provisions for a user-selectable voltage divider-filter included

Applications

  • Bidirectional current sense
  • Temperature measurement
  • Medical equipment
  • Electronic weigh scales

Documentation

= Featured Documentation
Type Title Date
Manual - Development Tools
ISL28133EVAL1Z User Guide
PDF 420 KB
Datasheet
ISL28133 Datasheet
PDF 6.09 MB
2 items

Design & Development

Product Options

    Processing table
    Buy / Sample
    Part Number
    ISL28133EVAL1Z
    circleActive
    Samples Available
    Buy Now
    		Get Samples,
