Overview
Description
The RZ/G2M reference board from HopeRun is compatible with 96Boards equipped with the Renesas RZ/G2M MPU. It consists of two boards, a main board, and a sub-board, and most of the RZ/G2M mounted functions can be evaluated by connecting to the sub-board.
For more information contact HopeRun Tokyo Co., Ltd.
Features
- Processor: RZ/G2M
- Main Memory: 4GB DDR4
- QSPI NOR Flash: 64MByte
- I2C EEPROM: 512Byte
- External Storage: micro SD x1
- Connectivity: USB 2.0 x 2ch, USB 3.0 x 1ch, GbE x 1
- HDMI out / LVDS out or MIPI DSI out
- Wi-Fi + BT
- PMIC
- Dimension: 54mm x 85mm
Applications
Documentation
Featured Documentation
Log in required to subscribe
|
|
|
|
|---|---|---|
| Type | Title | Date |
| Quick Start Guide | PDF 372 KB | |
1 item
|
||
Design & Development
Software & Tools
Software & Tools
| Software title
|
Software type
|
Company
|
|---|---|---|
| RZ/G Verified Linux Package [5.10-CIP] Linux Packages for MPUs of the RZ/G2 Group. Functions of this products have been verified and regular maintenance is also provided.
|
Software Package | Renesas |
| RZ/G Verified Linux Package for 64-bit Kernel [4.19-CIP] The Linux package which is for 64bit processors and offered by Renesas contains ported and tested basic software that is necessary for the industrial segment, in a software package for which operation and performance has been verified based on a datasheet. It enables you to start using a stable Linux environment and basic software immediately, so you can concentrate on developing your application.
|
Software Package | Renesas |
2 items
|
||
