Evaluation Kit for ZSSC3218
The ZSSC3218KIT Evaluation Kit provides the hardware needed for configuration, calibration and evaluation of the ZSSC3218 Sensor Signal Conditioner IC. The user's PC...
Featured Documents:
Overview
Description
The ZSSC32xx Evaluation Board is included in Renesas's modular SSC Evaluation Kits for select resistive ZSSC32xx sensor signal conditioner (SSC) ICs. It provides the minimum application circuit for evaluation of the SSC IC and a socket for mounting the IC. It can be ordered separately.
