Overview
Description
The RapidWave™ RWM6051 is a millimeter wave (mmWave) baseband wireless modem for wireless backhaul and fixed infrastructure wireless access applications. The RWM6051 delivers cost-effective and power-efficient solutions for the emerging backhaul and access markets. It can be paired with mmWave RF chipsets to deliver multi-gigabit throughput at several hundred meters distance. The RWM6051 is highly configurable with a radio interface that provides easy integration with RF solutions.
The RWM6051 features a high degree of configurability with flexible channelization modes and modulation coding to scale bandwidth up to multi-gigabit data rates. Internally, the RapidWave mode includes the mixed-signal front-end resulting in an integration strategy that delivers the most cost-effective and power-efficient solution.
The RWM6051 incorporates technology licensed from and developed in collaboration with Blu Wireless Technology. Blu Wireless Technology provides Typhoon Development Platforms for the Renesas RWM6051. Typhoon is a family of highly programmable wireless communication modules that leverage the Renesas RWM6051 device.
Before deploying your mmWave network, examine the range and throughput estimation for a wireless connection using your specific link characteristics. For more information, check out the Blu Wireless Technology mmWave Link Budget Calculator on the Blu Wireless website.
Features
- mmWave modem with PHY + MAC + ADC/DAC + beamforming subsystems
- Modulation and Channelization support
- Beamforming support with phased array antenna
- Extensions to support long distance transmission
- Digital front-end processing
- Programmable real-time scheduler
- Integrated network synchronization
Comparison
Applications
- Small cell backhaul
- mmWave mesh networking and distribution network
- Fixed wireless access
- Residential broadband backhaul and aggregation
- Enterprise and smart city networking
Design & Development
Software & Tools
Models
ECAD Models
Schematic symbols, PCB footprints, and 3D CAD models from SamacSys can be found by clicking on products in the Product Options table. If a symbol or model isn't available, it can be requested directly from the website.
Processing table
| FCBGA | 484 | I | Tray | 4 | 71.35 | Get Samples, |
Tips for Using This Parametric Table:
- Hide Filters button in header: Collapse or expands filters
- Column sort buttons in header: Sort Column alphabetically / numerically descending or ascending
- Reset button in header: Reset all filters to the page default
- Full Screen button in header: Expand the table to full screen view (user must close out of full screen before they can interact with rest of page)
- Export button in header: Export the filtered results of the table to an Excel document
- Filter parts search bar in header: Type to filter table results by part number
- Hide column button in column headers: Select to hide columns in table
- AND / OR toggle switches in header: Toggles the logic of this particular filter to be “AND” or “OR” logic for filtering results
- Multiselect checkboxes at beginning of each row in table: Select these checkboxes to compare products against each other
- Document icon next to product name in row: View the featured document for this product
- Chip icon next to the right of the document icon in row: View the block diagram for this product
- Cart icon to the right of the chip icon: Indicates that samples are available for this product
Videos & Training
RapidWave RWM6050 Introduction - mmWave Baseband Wireless Modem
An introduction to the RapidWave™ RWM6050, a millimeter wave (mmWave) baseband wireless modem for wireless backhauls and fixed infrastructure wireless access applications. The RWM6050 device delivers cost effective and power efficient solutions for the emerging backhaul and access markets. It can be paired with mmWave RF chipsets to deliver multi-gigabit throughput at several hundred meters distance. The RWM6050 is highly configurable with a radio interface that provides easy integration with RF solutions.
For more information about the RWM6050 visit the RWM6050 - RapidWave Baseband Modem page.
