Synchronous Step-Down PWM Regulator Evaluation Board
The EL7535 is a high-efficiency 350mA synchronous step-down PWM regulator in a tiny MSOP10 package. The internal compensation makes it possible for these full-featured...
Overview
Description
The EL7535 is a high-efficiency, 350mA synchronous step-down PWM regulator in a tiny 10 Ld MSOP package. The internal compensation makes it possible for these full-featured converters to occupy less than 0.18in2 of PCB area with all components on one side.
Features
- Internally compensated voltage mode controller
- Up to 94% efficiency
- Overcurrent and over-temperature protection
- Pb-free plus anneal available (RoHS compliant)
Applications
Applications
- PDA and pocket PC computers
- Barcode readers
- Cellular Phones
- Portable instruments
- Li-ion battery powered devices
- Small Form Factor (SFF) modules
