Dual-Channel Micropower Operational Amplifier Evaluation Board
The SLG88103V-EVB evaluation board is used to evaluate the SLG88103V dual-channel micropower operational amplifier for GreenPAK™.
The SLG88103 is a wide voltage range,...
Overview
Description
The SLG88103 is a wide voltage range, 375nA dual-channel CMOS input operational amplifier capable of rail-to-rail input and output operation. Each amplifier can be individually powered down.
Features
- Supply Voltage: 1.71V to 5.5V
- Low Quiescent Current: 375nA per Amplifier (typ.)
- Rail-to-Rail Input/Output
- Low Offset Voltage: ±200µV (typ.)
- Low Offset Drift: 1µV/°C (typ.)
- DC Precision
- PSRR: 115dB
- CMRR: 100dB
- AOL: 120dB
- Zero-Crossover
- Gain-Bandwidth Product: 10kHz (typ.)
- Industrial Temperature Range: -40 °C to 85 °C
Comparison
Applications
- Battery-Powered Devices
- Portable Devices
- Wearable Products
- Gas Sensors
- Pressure Sensors
- Medical Monitors
- Smoke Detectors
- Active RFID Reader
- Energy Harvester
