Overview
Description
Smart Analog IC501 has a built-in instrument amplifier and D/A converter. It is suitable for home appliances, industrial applications and healthcare equipment.
Features
- RAA730501CFP for industrial applications
- RAA730501DFP for consumer applications
- Input Mux 3 channels
- Instrumentation amplifier
- 8-bit D/A converter
- Variable output voltage regulator / LDO
- Reference voltage generator
- Temperature sensor
- SPI: 1 channel
- Low power consumption modes available
- Operating voltage range: 3.0 to 5.5 V
- Operating temperature range: Ta= -40 to +105°C
- Package: 48-pin LQFP (7 x 7)
Comparison
Applications
Applications
- Home appliances
- Industrial applications
- Healthcare equipment
Documentation
Log in required to subscribe
|
|
|
|
|---|---|---|
| Type | Title | Date |
| Training | PDF 258 KB | |
| Training | PDF 325 KB | |
| Application Note | PDF 1.50 MB 日本語 | |
| Application Note | PDF 1.27 MB 日本語 | |
| Flyer | PDF 8.02 MB 日本語 | |
|
5 items
|
||
