Overview
Description
The ISL55014 is a high performance gain block featuring a Darlington configuration using high fT transistors and excellent thermal performance. They are an ideal choice for DVB-S LNB cable receiver applications. Other members of the family includes: • ISL55012 and ISL55015 match a 75Ω source to a 50Ω load. • ISL55013 and ISL55014 match a 50Ω source to a 50Ω load.
Features
- Input impedance of 50Ω
- Output impedance of 50Ω
- Gain of 17.2dB at1GHz
- Noise figure of 4.3dB
- OIP3 of 30dBm
- Low input and output return losses
- Pb-free (RoHS compliant)
Comparison
Applications
Applications
- LNB and LNB-T (HDTV) amplifiers
- IF gain blocks for satellite and terrestrial STBs
- PA driver amplifier
- Wireless data, satellite
- Bluetooth/WiFi
- Satellite locator and signal strength meters
Documentation
= Featured Documentation
Log in required to subscribe
|
|
|
|
|---|---|---|
| Type | Title | Date |
| Datasheet | PDF 540 KB | |
| Training | PDF 258 KB | |
| Training | PDF 325 KB | |
| Product Advisory | PDF 447 KB | |
| Product Change Notice |
PCN12084A - Manufacturing Site Change for the Listed Intersil Products - Carsem (CAS) Ipoh, Malaysia
PDF
141 KB
|
|
| Product Change Notice | PDF 529 KB | |
| Product Change Notice | PDF 135 KB | |
| Application Note | PDF 357 KB | |
8 items
|
||
Design & Development
Models
ECAD Models
Schematic symbols, PCB footprints, and 3D CAD models from SamacSys can be found by clicking on products in the Product Options table. If a symbol or model isn't available, it can be requested directly from the website.
Processing table
ISL55014IEZ-T7 Active Samples Available
Buy Now
|
SC70 | Reel | 2 | Get Samples, |
