Overview
Description
The 71V016 3.3V CMOS SRAM is organized as 64K x 16. All bidirectional inputs and outputs of the 71V016 are LVTTL-compatible and operation is from a single 3.3V supply. Fully static asynchronous circuitry is used, requiring no clocks or refresh for operation.
Features
- Equal access and cycle times — Commercial: 10/12/15/20ns — Industrial: 12/15/20ns
- One Chip Select plus one Output Enable pin
- Bidirectional data inputs and outputs directly LVTTL-compatible
- Low power consumption via chip deselect
- Upper and Lower Byte Enable Pins
- Single 3.3V power supply
- Available in 44-pin Plastic SOJ, 44-pin TSOP, and 48-Ball Plastic FBGA packages
Comparison
Applications
Design & Development
Models
ECAD Models
Schematic symbols, PCB footprints, and 3D CAD models from SamacSys can be found by clicking on products in the Product Options table. If a symbol or model isn't available, it can be requested directly from the website.
Processing table
Pkg. Type |
Lead Count (#) |
Temp. Grade |
Pb (Lead) Free |
Carrier Type |
Moisture Sensitivity Level (MSL) |
Price (USD) | 1ku |
Buy / Sample |
|
|---|---|---|---|---|---|---|---|---|
| Part Number | ||||||||
| TSOP | 44 | C | Yes | Tray | 3 | 1.939 | Get Samples, | |
| TSOP | 44 | C | Yes | Reel | 3 | 2.69 | ||
| TSOP | 44 | I | Yes | Tray | 3 | Get Samples, | ||
| CABGA | 48 | C | No | Reel | 3 | |||
| CABGA | 48 | C | Yes | Tray | 3 | 4.553 | Get Samples, | |
| CABGA | 48 | C | Yes | Reel | 3 | |||
| TSOP | 44 | C | Yes | Tray | 3 | 2.503 | Get Samples, | |
| TSOP | 44 | C | Yes | Reel | 3 | |||
| TSOP | 44 | I | Yes | Tray | 3 | 2.178 | Get Samples, | |
| TSOP | 44 | I | Yes | Reel | 3 | 8.59 | ||
| TSOP | 44 | C | Yes | Tray | 3 | 1.952 | Get Samples, | |
| TSOP | 44 | C | Yes | Reel | 3 | 2.69 | ||
| TSOP | 44 | I | Yes | Tray | 3 | 4.299 | Get Samples, | |
| TSOP | 44 | I | Yes | Reel | 3 | 2.83 | ||
| TSOP | 44 | C | Yes | Tray | 3 | 2.503 | Get Samples, | |
| TSOP | 44 | C | Yes | Reel | 3 | 2.69 |
