Overview
Description
The 71V424 3.3V CMOS SRAM is organized as 512K x 8. All bidirectional inputs and outputs of the 71V424 are TTL-compatible and operation is from a single 3.3V supply. Fully static asynchronous circuitry is used, requiring no clocks or refresh for operation.
Features
- JEDEC Center Power/GND pinout for reduced noise
- Equal access and cycle times
- Commercial and Industrial: 10/12/15ns
- Single 3.3V power supply
- One Chip Select plus one Output Enable pin
- Bidirectional data inputs and outputs directly
- TTL-compatible
- Low power consumption via chip deselect
- Available in 36-pin, 400 mil plastic SOJ and 44-pin, 400 mil TSOP packages
Comparison
Applications
Design & Development
Models
ECAD Models
Schematic symbols, PCB footprints, and 3D CAD models from SamacSys can be found by clicking on products in the Product Options table. If a symbol or model isn't available, it can be requested directly from the website.
Processing table
Pkg. Type |
Lead Count (#) |
Temp. Grade |
Pb (Lead) Free |
Carrier Type |
Moisture Sensitivity Level (MSL) |
Price (USD) | 1ku |
Buy / Sample |
|
|---|---|---|---|---|---|---|---|---|
| Part Number | ||||||||
| TSOP | 44 | C | Yes | Tray | 3 | 6.1 | Get Samples, | |
| TSOP | 44 | C | Yes | Reel | 3 | |||
| TSOP | 44 | I | Yes | Tray | 3 | 6.287 | Get Samples, | |
| TSOP | 44 | I | Yes | Reel | 3 | |||
| TSOP | 44 | C | Yes | Reel | 3 | |||
| TSOP | 44 | I | Yes | Tray | 3 | 7.408 | Get Samples, | |
| TSOP | 44 | I | Yes | Reel | 3 | |||
| TSOP | 44 | C | Yes | Tray | 3 | 6.484 | Get Samples, | |
| TSOP | 44 | C | Yes | Reel | 3 | |||
| TSOP | 44 | I | Yes | Reel | 3 | |||
| TSOP | 44 | C | Yes | Tray | 3 | 7.188 | Get Samples, | |
| TSOP | 44 | C | Yes | Reel | 3 | |||
| TSOP | 44 | I | Yes | Tray | 3 | 7.195 | Get Samples, | |
| TSOP | 44 | I | Yes | Reel | 3 | |||
| TSOP | 44 | C | Yes | Reel | 3 | 9.01 | ||
| TSOP | 44 | I | Yes | Reel | 3 | 9.01 |
