Overview

The SLG59M1568V single N-channel load switch is designed for load switching applications. The device comes with one 9A-rated MOSFET switched on by an ON control pin. Turn-on time for the MOSFET is independently adjusted by an external capacitor.

SLG59M1568V Diagram
SLG59M1568V Diagram
  • Optimized for smartphone, notebook/tablet PC applications
  • 7.3mΩ RDSON while supporting 9A
  • Power supply: 2.5V ≤ VDD ≤ 5.5V
  • Input voltage range: 1.0V ≤ VD ≤ VDD
  • Output voltage slew-rate control by an external capacitor
  • Overcurrent and over-temperature protection
  • Output discharge circuitry
  • Sleep mode current (IDDOFF) in low µA range

Applications

  • Consumer Electronics
  • Portable Tablets and Notebooks
  • PCs and PC Peripherals
  • Commercial and Industrial Electronics
  • Printers
  • Servers
  • Embedded PCs
  • Data Communications Equipment

Documentation

= Featured Documentation
Type Title Date
Datasheet
SLG59M1568V Datasheet
PDF 348 KB
Guide
GreenFET Product Selection Guide
PDF 2.76 MB
Brochure
GreenFET Robust Load Switches
PDF 5.06 MB
Application Note
AN-CM-289 GreenFET Load Switches Thermal Considerations for PCB Layout
PDF 1.27 MB
Application Note
AN-CM-272 Extending the GreenFET Load Switch Maximum Operating Current
PDF 911 KB
Other
SLG59M1568V Layout Guide
PDF 292 KB
6 items

Design & Development

Software Downloads
Type Title Date
PCB Design Files
GreenFET Altium Library
ZIP 65 KB
PCB Design Files
GreenFET Eagle Library
ZIP 9 KB
PCB Design Files
GreenFET OrCAD Library
ZIP 221 KB
PCB Design Files
High Voltage GreenFET Altium Library
ZIP 23 KB
PCB Design Files
High Voltage GreenFET Eagle Library
ZIP 2 KB
PCB Design Files
High Voltage GreenFET OrCAD Library
ZIP 61 KB
6 items
SLG59M1568V-EVB

SLG59M1568V-EVB

Evaluation
Learn More

SLG59M1568V Evaluation Board

The SLG59M1568V-EVB board evaluates the SLG59M1568V GreenFET, Single N-Channel, Load Switch.

ECAD Models

Schematic symbols, PCB footprints, and 3D CAD models from SamacSys can be found by clicking on products in the Product Options table. If a symbol or model isn't available, it can be requested directly from the website.

Explore ECAD Models
Diagram of ECAD Models

Product Options

    Processing table
    Pkg. Type
    Carrier Type
    Moisture Sensitivity Level (MSL)
    Price (USD) | 1ku
    Buy / Sample
    Part Number
    SLG59M1568V
    circleActive
    memory
    view_in_ar
    Buy Now
    		STDFN-14 Tape & Reel 1
    SLG59M1568VTR
    info
    memory
    view_in_ar
    		STDFN-14
