The MCU unit is a MCU-dependent hardware tool for the E100 emulator. Connecting it to the E100 emulator main unit allows you to configure a debugging environment for your target system. It is easy for the user to replace. [Learn More]
Target Devices
Documentation
Log in required to subscribe
|
|
|
|
|---|---|---|
| Type | Title | Date |
| Manual - Development Tools | PDF 4.30 MB 日本語 | |
| Tool News - Release | PDF 582 KB 日本語 | |
| Release Note | PDF 96 KB 日本語 | |
| Release Note | PDF 57 KB 日本語 | |
| Manual - Development Tools | PDF 300 KB 日本語 | |
| Manual - Development Tools | PDF 338 KB 日本語 | |
| Manual - Development Tools | PDF 331 KB 日本語 | |
| Manual - Development Tools | PDF 283 KB 日本語 | |
8 items
|
||
Additional Details
Specifications
| Item | Description | |
|---|---|---|
| Applicable emulator | E100 | |
| Supported MCUs | H8S/2400 Series MCUs | |
| Applicable MCU mode | Single-chip mode, On-chip ROM disabled extended mode, On-chip ROM enabled extended mode |
|
| Maximum ROM/RAM capacity | (1) Internal flash ROM : 512KB (2) Internal RAM : 128KB (3) Internal Data Flash : 8KB |
|
| Maximum operating frequency | 33MHz | |
| Power supply voltage | 3.0～3.6[V],4.5～5.5[V] | |
| Emulator power supply | Supplied from the DC power of the emulator | |
| Overseas standards | ・European Standards: EN 55022 Class A, EN 55024 ・US FCC Standard: FCC part 15 Class A |
|
Components
- MCU unit (R0E424270MCU00)
- Flexible cable (Mounted on the MCU unit)
- 16.5MHz oscillator module (Mounted on the MCU unit)
- CD-ROM (H8S/Tiny H8S/2400 E100 emulator software)
- H8S/Tiny H8S/2400 E100 emulator debugger (Including High-performance Embedded Workshop)
- Auto-update utility
- User's manual
