Overview
Description
The AIK-RA8D1 provides developers with multiple and reconfigurable connectivity functions to expedite AI/ML system development. This easy-to-use hardware platform for multimodal AI/ML solutions is based on the RA8D1 MCU from the RA family of 32-bit MCUs.
The hardware platform is intended for use in a variety of AI/ML single or multimodal use cases supporting vision, real-time analytics, and audio. It enables multiple combinations of different plug-in sensors with the available onboard analog microphones and camera.
The kit is supported by Reality AI Software for real-time analytics, and by the Renesas Ready Partner Network for specific vision and audio-based use cases.
The AIK-RA8D1 will enable you to evaluate and test available application examples, as well as develop your own solutions using the available ecosystem and AI/ML software.
Features
- Hardware Features
- Renesas RA8D1 480MHz Arm-Cortex-M85 based microcontroller with Helium and TrustZone
- Up to six Digilent Pmod™ ports (SPI/UART/I2C) for sensors and peripherals connectivity allowing rapid prototyping
- Camera and analog microphones interface
- Ethernet and CAN interfaces
- External SDRAM (128Mbit)
- Micro USB Full Speed device support
- SEGGER J-Link® on board debugger with Virtual COM port functionality
- Add-on AI Features
- Out of the box application example – Asset Movement Detection created by Reality AI Tools
- Various AI/ML solutions from the Renesas Ready Partner Network
Applications
- Edge AIoT applications
- Agriculture
- Home automation
- Consumer
- Transport and logistics
- Building automation
- Healthcare
- City infrastructure
- Industrial automation
Documentation
|
|
|
|
|---|---|---|
| Type | Title | Date |
| Quick Start Guide | PDF 1.10 MB | |
| Manual - Development Tools | PDF 999 KB | |
| Schematic | ZIP 76.91 MB | |
3 items
|
||
Design & Development
Software
Supporting content such as a Board Support Package (BSP) and Quick Setup Guide (QSG) are available from the Renesas Ready Solutions Repository on GitHub.
Software & Tools
Software & Tools
| Software title
|
Software type
|
Company
|
|---|---|---|
| RA Flexible Software Package (FSP) FSP is an enhanced software package designed to provide easy-to-use, scalable, high-quality software for embedded system designs using Renesas RA Family of Arm Microcontrollers.
Note: FSP with e² studio Installer (Platform Installer) will install the e² studio tool, FSP packs, GCC toolchain, and Segger J-Link drivers required to use this software. No additional installations are required.
|
Software Package | Renesas |
| Reality AI Tools Reality AI Tools® users automatically explore sensor data and generate optimized models.
|
Solution Toolkit | Renesas |
| Reality AI Utilities Plug-in module for Renesas e² studio
|
Solution Toolkit | Renesas |
3 items
|
||
