概要
説明
The 74FCT163245 16-bit high-speed, low-power transceivers are ideal for asynchronous communication between two buses. The Direction and Output Enable controls are designed to operate these devices as either two independent 8-bit transceivers or one 16-bit transceiver. The 74FCT163245 operates at -40C to +85C
特長
- A and C speeds
- Typical tSK(o) (Output Skew) 250ps
- ESD > 2000V per MIL-STD-883, Method 3015
- > 200V using machine model (C = 200pF, R = 0)
- VCC = 3.3V ± 0.3V, Normal Range, or VCC = 2.7V to 3.6V, Extended Range
- CMOS power levels (0.4 uW typ. static)
- Rail-to-rail output swing for increased noise margin
- Low Ground Bounce (0.3V typ.)
- Inputs (except I/O) can be driven by 3.3V or 5V components
- Available in 48 pin SSOP, TSSOP, and TVSOP packages
製品比較
アプリケーション
設計・開発
モデル
ECADモデル
[製品選択]テーブル内の製品名をクリックするとSamacSysが提供する回路図シンボル、PCBフットプリント、3D CADモデルがご確認いただけます。 お探しのシンボルやモデルが見つからない場合、Webサイトから直接リクエストできます。
Processing table
Pkg. Type |
Lead Count (#) |
Temp. Grade |
Pb (Lead) Free |
Carrier Type |
Price (USD) | 1ku |
ご購入 / サンプル |
|
|---|---|---|---|---|---|---|---|
| 型名 | |||||||
| TSSOP | 48 | C | Yes | Tube | 1.679 | ||
| TSSOP | 48 | C | Yes | Reel | |||
| TVSOP | 48 | C | Yes | Tube | |||
| TVSOP | 48 | C | Yes | Reel | |||
| SSOP | 48 | C | Yes | Tube | |||
| SSOP | 48 | C | Yes | Reel | |||
| TSSOP | 48 | C | Yes | Tube | 1.44 | ||
| TSSOP | 48 | C | Yes | Reel | |||
| TVSOP | 48 | C | Yes | Tube | |||
| TVSOP | 48 | C | Yes | Reel | |||
| SSOP | 48 | C | Yes | Tube | 1.441 | ||
| SSOP | 48 | C | Yes | Reel |
