DK-S124 Development Kit
Evaluate all features of the Synergy™ S124 microcontroller (MCU) Group and develop low power applications using Synergy software and tools.
Part number of this kit...
Featured Documents:
Overview
Description
Uniquely suited for simple battery-operated sensing applications that require low power operation modes and fast wake-up times, the S124 MCU Group has 128KB of flash memory and 16KB of SRAM. It includes a 14-bit A/D converter, 12-bit D/A converter, and a Capacitive Touch Sensing Unit (CTSU), in addition to safety and security features.
Synergy Software Package (SSP)
Commercial software worth over $100K which is available to developers using the Synergy Platform for no charge and with unlimited production license rights. The production-ready SSP is fully tested, maintained, and supported by Renesas.
Features
- 32MHz Arm® Cortex®-M0+ CPU
- For battery-operated sensing applications that require low power operation modes and fast wake-up times
- 14-bit A/D converter, 12-bit D/A converter
- Capacitive Touch Sensing Unit
- Safety and security features.
Comparison
Applications
- Wireless motion detector
Design & Development
Software & Tools
Software & Tools
| Software title
|
Software type
|
Company
|
|---|---|---|
| QE for Capacitive Touch: Development Assistance Tool for Capacitive Touch Sensors In developing embedded system using the capacitive touch sensor of MCUs, you can easily setup initial configurations of the touch interface as well as process the tuning of sensors, and reduce development time. [Plugin for Renesas IDE "e2 studio"] [Standalone Version] [Support MCU/MPU:RA, RL78, RX, Renesas Synergy™]
|
Solution Toolkit | Renesas |
| Renesas Synergy™ Software Package (SSP) A tightly integrated, optimized, and qualified suite of software with a commercial RTOS that scales with end-product complexity that simplifies complex system-level services.
|
Software Package | Renesas |
2 items
|
||
Sample Code
Boards & Kits
AE-CAP1 - Capacitive Touch Application
Evaluate capacitive touch technology on the Renesas Synergy™ Platform and develop with the Synergy S124 and S3A7 MCU Groups.
Kit Contents
- AE-CAP1-BWS...
Featured Documents:
Motor Control Evaluation System for RA Family - RA6T1 Group
The Motor Control Evaluation System for RA Family - RA6T1 Group is a low-voltage permanent magnet synchronous motor (brushless DC motor) solution that allows anyone to...
MCK-RA6T2 Renesas Flexible Motor Control Kit for RA6T2 MCU Group
The MCK-RA6T2 is a development kit that enables easy evaluation of motor control using permanent magnet synchronous motors (brushless DC motors). With this product and...
Featured Documents:
Models
ECAD Models
Schematic symbols, PCB footprints, and 3D CAD models from SamacSys can be found by clicking on products in the Product Options table. If a symbol or model isn't available, it can be requested directly from the website.
Processing table
Program Memory (KB) |
Data Flash (KB) |
SRAM |
Lead Count (#) |
Pkg. Type |
PLP |
Operating Voltage Range (V) |
Operating Freq (Max) (MHz) |
DAC |
I/O Ports |
CAN (ch) |
Safety |
Security & Encryption |
Family Name |
DMA |
Ethernet |
Moisture Sensitivity Level (MSL) |
Price (USD) | 1ku |
Buy / Sample |
|
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Part Number | |||||||||||||||||||
| 64 | 4 | 16 KB | 64 | LFQFP | 2031 Jun | 1.6 - 5.5 | 32 | 12-bit x 1-ch | 51 | 1 | Yes | 128-bit Unique ID, AES128, AES256, TRNG | Synergy MCU | No | No | 3 | 2.137 | Get Samples, | |
| 64 | 4 | 16 KB | 48 | LFQFP | 2031 Jun | 1.6 - 5.5 | 32 | 12-bit x 1-ch | 35 | 1 | Yes | 128-bit Unique ID, AES128, AES256, TRNG | Synergy MCU | No | No | 3 | 2.657 | Get Samples, | |
| 128 | 4 | 16 KB | 48 | LFQFP | 2031 Jun | 1.6 - 5.5 | 32 | 12-bit x 1-ch | 35 | 1 | Yes | 128-bit Unique ID, AES128, AES256, TRNG | Synergy MCU | No | No | 3 | 2.956 | Get Samples, | |
| 128 | 4 | 16 KB | 64 | LFQFP | 2031 Jun | 1.6 - 5.5 | 32 | 12-bit x 1-ch | 51 | 1 | Yes | 128-bit Unique ID, AES128, AES256, TRNG | Synergy MCU | No | No | 3 | 2.337 | Get Samples, | |
| 64 | 4 | 16 KB | 48 | LFQFP | 2036 Mar | 1.6 - 5.5 | 32 | 12-bit x 1-ch | 35 | 1 | Yes | 128-bit Unique ID, AES128, AES256, TRNG | Synergy MCU | No | No | 3 | 2.745 | ||
| 64 | 4 | 16 KB | 64 | LFQFP | 2036 Mar | 1.6 - 5.5 | 32 | 12-bit x 1-ch | 51 | 1 | Yes | 128-bit Unique ID, AES128, AES256, TRNG | Synergy MCU | No | No | 3 | |||
| 128 | 4 | 16 KB | 48 | LFQFP | 2036 Mar | 1.6 - 5.5 | 32 | 12-bit x 1-ch | 35 | 1 | Yes | 128-bit Unique ID, AES128, AES256, TRNG | Synergy MCU | No | No | 3 | 2.65 | ||
| 64 | 4 | 16 KB | 48 | LFQFP | N/A | 1.6 - 5.5 | 32 | 12-bit x 1-ch | 35 | 1 | Yes | 128-bit Unique ID, AES128, AES256, TRNG | Synergy MCU | No | No | 3 | |||
| 128 | 4 | 16 KB | 48 | LFQFP | N/A | 1.6 - 5.5 | 32 | 12-bit x 1-ch | 35 | 1 | Yes | 128-bit Unique ID, AES128, AES256, TRNG | Synergy MCU | No | No | 3 | 2.956 | ||
| 128 | 4 | 16 KB | 64 | LFQFP | 2036 Mar | 1.6 - 5.5 | 32 | 12-bit x 1-ch | 51 | 1 | Yes | 128-bit Unique ID, AES128, AES256, TRNG | Synergy MCU | No | No | 3 |
