Overview

Topics
[Upgrade to Revision] Solution Toolkit QE for OTA V2.1.0: Development Assistance Tool for Cloud (PDF | English, 日本語)
・RA Family RA6M4 and RA6M5 groups Support
　-Added MCUboot Settings function
・Support FreeRTOS v202210.01-LTS-rx-1.3.1 (LTS #2)
・Support AzureRTOS 6.4.0_rel-rx-1.0.0

QE for OTA is a development assistance tool that enables easy trial of over-the-air (OTA) firmware updates with cloud services (AWS, Azure).

  • Enables easy introduction of RTOS projects
  • Automates various cloud settings such as creating those for IoT devices
  • Creating initial firmware required for OTA updates and support for the debugging and programming of devices
  • Creating firmware updates, uploading the firmware to the cloud, and making settings required for OTA updates
Product NameLatest Ver.ReleasedTaget Device (Note1)DetailsDownload(Note2)Operating Environment
QE for OTAV2.1.0Oct 31, 2024RX Family
RL78 Family
RA Family		See Release NoteDownloadOperating Environment

Notes

  1. For detailed support devices, refer to Target Devices
  2. Installing this Product >>

Downloads
Type Title Date
Software & Tools - Software
QE for OTA V2.1.0: Development Assistance Tool for Cloud
Log in to Download ZIP 90.17 MB 日本語
1 item

Documentation

Design & Development

Related Pages
e² studio - Information for the RX Family
Eclipse-based Renesas integrated development environment (IDE).
Downloads
[Upgrade to Revision] Solution Toolkit, Development Assistance Tool for Cloud, QE for OTA V1.1.0 [Technical Preview Edition][Upgrade to Version] Solution Toolkit QE for OTA V2.0.0: Development Assistance Tool for Cloud[Upgrade to Revision] Solution Toolkit QE for OTA V2.1.0: Development Assistance Tool for Cloud
 IDE and Coding Tool Renesas
e² studio - information for RL78 Family
Eclipse-based Renesas integrated development environment (IDE).
Downloads
[Upgrade to Version] Solution Toolkit QE for OTA V2.0.0: Development Assistance Tool for Cloud[Upgrade to Revision] Solution Toolkit QE for OTA V2.1.0: Development Assistance Tool for Cloud
 IDE and Coding Tool Renesas
RL78 Smart Configurator
RL78 Smart Configurator is a utility for combining software in ways that meet your needs. It simplifies the embedding of Renesas drivers in your systems through supports for importing middleware and drivers and configuring pins.
 Solution Toolkit Renesas
E2 emulator [RTE0T00020KCE00000R]
On-chip debugging emulator. Also available as a flash memory programmer. [Support MCU/MPU: RA, RE, RH850, R-Car D1, RL78, RX, RISC-V MCU]
 Emulator Renesas
E2 emulator Lite [RTE0T0002LKCE00000R]
On-chip debugging emulator. Also available as a flash memory programmer. [Support MCU/MPU: RA, RE, RL78, RX, RISC-V MCU]
 Emulator Renesas
Renesas Flash Programmer (Programming GUI)
Flash memory programming software [Support MCU/MPU and devices: RA, RE, RX, RL78, RH850, RISC-V MCU Renesas Synergy, DA1453x, DA1459x, DA1469x, DA1470x, Power Management, Renesas USB Power Delivery Family, ICs for Motor Driver/Actuator Driver, V850, 78K0R, 78K0]
 Programmer (Unit/SW) Renesas
e² studio - information for RA Family
Eclipse-based Renesas integrated development environment (IDE). [Support MCU/MPU: RA, RE, RX, RL78, RH850, Renesas Synergy, RZ]
Downloads
[Upgrade to Revision] Solution Toolkit QE for OTA V2.1.0: Development Assistance Tool for Cloud
 IDE and Coding Tool Renesas
RA Flexible Software Package (FSP)
FSP is an enhanced software package designed to provide easy-to-use, scalable, high-quality software for embedded system designs using Renesas RA Family of Arm Microcontrollers. Note: FSP with e² studio Installer (Platform Installer) will install the e² studio tool, FSP packs, GCC toolchain, and Segger J-Link drivers required to use this software. No additional installations are required.
 Software Package Renesas
8 items
RL78/G23-128p Fast Prototyping Board with Box

RTK7RLG230CSN000BJ

Evaluation
Learn More

RL78/G23-128p Fast Prototyping Board (RL78/G23-128p FPB)

The RL78/G23-128p Fast Prototyping Board comes equipped with an RL78/G23 microcontroller and is an evaluation board specialized for prototype development for a variety...

Featured Documents:
RL78/G23-128p Fast Prototyping Board Quick Start Guide Rev.1.00
CK-RX65N Baseboard

CK-RX65N

Development
Learn More

Cloud Kit Based on RX65N MCU Group

The CK-RX65N cloud kit enables users to securely connect to the cloud and explore the features of the Renesas RXv2 core based RX65N MCU Group and cloud services.

With...

Featured Documents:
CK-RX65N v2 – User's Manual
CK-RX65N v2 – Quick Start Guide
AWS Cloud Connectivity on CK-RX65N v2 with Wi-Fi DA16600 – Getting Started Guide
Renesas Starter Kit+ for RX65N-2MB

RX65N-2MB-Starter-Kit-Plus

Starter
Learn More

Renesas Starter Kit+ for RX65N-2MB

The Renesas Starter Kit+ for RX65N-2MB is the perfect starter kit for developers who are new to the RX65N (Code Flash 2MB, Pin Count 176-pin). The kit includes an LCD...

Renesas RX65N Cloud Kit

RX65N-Cloud-Kit

Evaluation
Learn More

Renesas RX65N Cloud Kit

The Renesas RX65N Cloud Kit is an RX65N microcontroller-based cloud communications evaluation kit which is an ideal evaluation environment for IoT device developers....

Featured Documents:
Quick Start Guide for Pre-Installed Demo with the RX65N Cloud Kit
CK-RA6M5 Baseboard

CK-RA6M5

Development
Learn More

Cloud Kit Based on RA6M5 MCU Group

The CK-RA6M5 cloud kit enables users to securely connect to the cloud and explore the features of the Cortex®-M33 based RA6M5 group of MCUs and cloud services. With...

Featured Documents:
CK-RA6M5 v2 – Quick Start Guide
EK-RA6M5 Kit

EK-RA6M5

Evaluation
Learn More

Evaluation Kit for RA6M5 MCU Group

The EK-RA6M5 evaluation kit enables users to effortlessly evaluate the features of the RA6M5 MCU Group and develop embedded systems applications using the Flexible...

Featured Documents:
EK-RA6M5 – Quick Start Guide
EK-RA6M5 v1 – User's Manual
EK-RA6M5 v1 - Design Package
EK-RA6M4 Kit

EK-RA6M4

Evaluation
Learn More

Evaluation Kit for RA6M4 MCU Group

The EK-RA6M4 evaluation kit enables users to effortlessly evaluate the features of the RA6M4 MCU Group and develop embedded systems applications using the Flexible...

Featured Documents:
EK-RA6M4 – Quick Start Guide
EK-RA6M4 v1 - User's Manual
EK-RA6M4 v1 - Design Package

Videos & Training

QE for OTA Tutorial : How to implement Microsoft Azure ADU by using Azure on RX65N

QE for OTA Tutorial: How to implement FreeRTOS OTA by using Microsoft Azure on RX65N
This tutorial walks you through setting up Microsoft Azure, creating initial firmware, and executing OTA with updated firmware using QE for OTA.

00:00 Opening
00:15 Preparing the demo project
04:10 Preparing initial firmware
06:15 Executing OTA

Video List
QE for OTA Tutorial : How to implement Microsoft Azure ADU by using Azure on RX65N
QE for OTA Tutorial: How to Implement FreeRTOS OTA by Using Amazon Web Services on RX65N

News & Blog Posts

Blog Post Sep 6, 2023
Blog Post Apr 19, 2023

Additional Details

Features

Simply proceed through the workflow to realize over-the-air (OTA) firmware updates via the AWS cloud.

QE for OTA provides a graphical user interface that allows you to set up the cloud, import sample projects, manage IoT devices, create firmware, and start OTA updates.

OTA_MainView



View for creating firmware for individual IoT devices and starting OTA updates

The [OTA Manage IoT Device (QE)] view, which is used to manage IoT devices, has the following features.

  • Creating and downloading a device certificate and security key for each IoT device
  • Creating an initial version of firmware (with the source code including IoT-device specific information)
  • Support for programming boards with the initial firmware
  • Creating firmware updates (with the source code including IoT-device specific information
  • Uploading firmware updates to the cloud and starting OTA updates
viewIoTDeviceManager-en



Supported Driver and Middleware

Releases - renesas/iot-reference-rx - GitHub
202210.01-LTS-rx-1.1.3, 202210.01-LTS-rx-1.2.1, FreeRTOS v202210.01-LTS-rx-1.3.1
Releases - renesas/amazon-freertos - GitHub
202107.00-rx-1.0.0, 202107.00-rx-1.0.1
Releases - renesas/azure-rtos - GitHub
6.2.1_rel-rx-1.0.0, 6.2.1_rel-rx-1.0.1, 6.4.0_rel-rx-1.0.0
Releases - renesas/iot-reference-rl78 - GitHub
v202210.01-LTS-rl78-1.0.0, v202210.01-LTS-rl78-1.1.0 (Supported LTE only, not Wi-Fi)

The combinations of the confirmed board and OTA sample program (including RTOS)

Board or KitOTA sample projects(including RTOS)
CK-RX65N v1FreeRTOS v202107.00-rx-1.0.1, FreeRTOS v202210.01-LTS-rx-1.1.3(LTS #2), FreeRTOS v202210.01-LTS-rx-1.2.1 (LTS #2), FreeRTOS v202210.01-LTS-rx-1.3.1 (LTS #2)
AzureRTOS 6.2.1_rel-rx-1.0.0, AzureRTOS 6.2.1_rel-rx-1.0.1, AzureRTOS 6.4.0_rel-rx-1.0.0
CK-RX65N v2 (Wi-Fi)  (Recommended)FreeRTOS v202210.01-LTS-rx-1.2.1 (LTS #2), FreeRTOS v202210.01-LTS-rx-1.3.1 (LTS #2)
RX65N-Cloud-Kit (Note1)FreeRTOS v202107.00-rx-1.0.0, FreeRTOS v202107.00-rx-1.0.1
RX65N-2MB-Starter-Kit-Plus (Note1)FreeRTOS v202107.00-rx-1.0.0, FreeRTOS v202107.00-rx-1.0.1
RL78/G23-128p Fast Prototyping BoardFreeRTOS v202210.01-LTS-rl78-1.0.0,FreeRTOS v202210.01-LTS-rl78-1.1.0 (Supported LTE only, not Wi-Fi)
CK-RA6M5 v2Sample project included in the application note "RA AWS CloudConnectivity and Firmware Update OTA on CK RA6M5 v2 with Ethernet (R11AN0915)”
EK-RA6M5MCUboot function only
EK-RA6M4MCUboot function only

Note
      1. Although the operation has been confirmed, it is recommended to use the CK-RX65N.

The confirmed debugging tools
