RH850/E2x 292pin Piggyback Board of RH850 Evaluation Platform
The RH850/E2X 292pin Piggyback Board supports all devices of the RH850/E2M and RH850/E2x-FCC1 series in 292pin-package. It can be used standalone or in combination with...
Overview
Description
The RH850 Generation 1 Network-Mainboard provides additional communication interfaces to the RH850 Piggyback boards in comparison to the RH850 Generation 1 Base-mainboard. The modular RH850 Evaluation System consisting of mainboards and piggyback boards is a platform for evaluating features and performance of Renesas 32-bit RH850 microcontrollers.
Features
- Adaptation headers to connect MCU Piggyback boards
- 12V power supply connection
- 2 DC-DC Regulators (configurable for 1.25V, 3.3V, 5.0V)
- DC Power Jack (ID=2.1mm, center positive) as well as 4mm Banana Jacks (1x red, 1x black)
- 4x Signal LEDs (Active High)
- 3x Push buttons, 2x Analog Input Potentiometers
- TFT touch Display Interface (Arduino Standard)
- Breadboard area
- Communication interfaces
- 8x CAN(-FD) ports
- 16x LIN ports
- 1x FlexRay port (with two channels)
- 1x Ethernet port (selectable either for BroadR-Reach® or RJ45)
- 2x UART/RS232 ports
Applications
Documentation
= Featured Documentation
