RL78/G23-64p Fast Prototyping Board (RL78/G23-64p FPB)
The RL78/G23-64p Fast Prototyping Board is an evaluation board based on the RL78/G23 microcontroller and is specifically designed for prototyping various applications....
Overview
Description
The RL78/G23 microcontroller group is a new generation of the RL78 family of microcontrollers, with 41μA/MHz CPU operation. The RL78/G23 group has the industry’s lowest power consumption with 210nA at stop (4KB SRAM retention), and a snooze mode sequencer which significantly reduces power consumption during intermittent operation. The RL78/G23 group features a wide operating voltage range of 1.6V to 5.5V at up to 32MHz, a broad range of package pin counts from 30 pins to 128 pins, and up to 768KB of flash memory. In addition to enhanced analog and security features, it also incorporates logic and event link controllers (ELCL) and the first capacitive touch sensing unit (CTSU2L) in the RL78 family. A rich development environment is also provided for the RL78/G23, including a fast prototyping board. This board allows users to write and debug programs with an easy-to-use GUI, by simply connecting a USB cable and a smart configurator without any additional tools required. The RL78/G23 is compatible with the existing RL78 family and can be a seamless replacement, making it suitable for a wide range of applications, from home appliance and consumer electronics to industrial equipment.
Features
- CPU: RL78 core, Max. 32MHz
- Up to 768kB Flash Memory and 48kB SRAM
- Memory: SRAM up to 48KB, Program Flash up to 768KB
- 8KB Data Flash to store data as in EEPROM
- Scalable from 30-pin to 128-pin packages
- Wide operating voltage range of 1.6V to 5.5V
- Enhanced Capacitive Sensing Unit (CTSU2L)
- Timer: 16-bit Timer (ch) x 16, 8-bit Timer, Watchdog Timer (ch) x 1,32-bit Interval Timer (ch) x 1
- PWM: PWM Output x 14
- Analog function: 12-bit A/D Converter (ch) x 26, 8-bit D/A - Converter (ch) x 2, Comparator x 2
- On-chip Oscillator Freq. (MHz): High-Speed: up to 32MHz
- Middle-Speed: up to 4MHz
- Low-speed: 32.768kHz
- Snooze mode sequencer
- Logic & Event link controller
- Others: RTC, Power-On Reset, Low Voltage Detection
- A large selection of packages (LQFP, QFN, LGA, BGA, WLCSP)
Comparison
Applications
Applications
- General Purpose
- Consumer applications
- Home Appliance
- Industrial Automation
- Building Automation
Design & Development
Software & Tools
Software & Tools
| Software title
|
Software type
|
Company
|
|---|---|---|
| RI78V4 V2 Real-time OS for RL78 Family μITRON Specification real-time OS for RL78 Family [Required IDE : CS+]
|
ITRON OS | Renesas |
| RL78 Web Simulator Right online tools to support initial evaluation of the low power consumption RL78 Family. Lineup: MCU Simulator Online and Current Consumption Calculator. Free of charge.
|
Simulator | Renesas |
| C Compiler Package for RL78 Family [CC-RL] C Compiler Package for RL78 Family [IDE: CS+, e² studio]
|
Compiler/Assembler | Renesas |
| QE for Current Consumption: A Dedicated Tool for Current Measurement Development assistance tool helps to shorten the times taken in operations for the tuning of currents drawn. [Standard item in the "e² studio" and CS+ (CS+ for CC only) IDEs] [Support MCU/MPU: RX, RL78]
|
Solution Toolkit | Renesas |
| QE for Capacitive Touch: Development Assistance Tool for Capacitive Touch Sensors In developing embedded system using the capacitive touch sensor of MCUs, you can easily setup initial configurations of the touch interface as well as process the tuning of sensors, and reduce development time. [Plugin for Renesas IDE "e2 studio"] [Standalone Version] [Support MCU/MPU:RA, RL78, RX, Renesas Synergy™]
|
Solution Toolkit | Renesas |
| E2 emulator [RTE0T00020KCE00000R] On-chip debugging emulator. Also available as a flash memory programmer. [Support MCU/MPU: RA, RE, RH850, R-Car D1, RL78, RX, RISC-V MCU]
|
Emulator | Renesas |
| E2 emulator Lite [RTE0T0002LKCE00000R] On-chip debugging emulator. Also available as a flash memory programmer. [Support MCU/MPU: RA, RE, RL78, RX, RISC-V MCU]
|
Emulator | Renesas |
| CS+ Renesas integrated development environment (IDE) [Support MCU/MPU: RH850, V850, RX, RL78, 78K0R, 78K0]
(Note: CS+ is not generally promoted to U.S. and European customers.)
(Note: To use Smart Configurator on CS+ for RL78/G23 and RX family MCUs, install the Smart Configurator for each MCU family separately downloading from ”Design & Support” > ”Development Tools” > ”Smart Configurator”)
|
IDE and Coding Tool | Renesas |
| CS+ Partner OS Aware Debugging Plug-in Features for task level debugging of real-time OS applications [Plugin for Renesas IDE CS+] [Support MCU/MPU: RX, RL78]
|
Plug-in, OS Aware Debugging, Etc. | Renesas |
| PG-FP6 Flash memory programmer [Programming software: Dedicated GUI-based software, the "FP6 Terminal"] [Support MCU/MPU and devices: RA, RE, RX, RL78, RH850, RISC-V MCU, Renesas Synergy, Power Management, Renesas USB Power Delivery Family, ICs for Motor Driver/Actuator Driver, SuperH RISC engine, V850, 78K, R8C]
|
Programmer (Unit/SW) | Renesas |
| Simulator for e² studio of RL78 Family Simulator for RL78 Family [Support IDE: e² studio] (Note: This product is included in the Renesas IDE "e² studio" and is not available separately.)
|
Simulator | Renesas |
| Renesas Flash Programmer (Programming GUI) Flash memory programming software [Support MCU/MPU and devices: RA, RE, RX, RL78, RH850, RISC-V MCU Renesas Synergy, DA1453x, DA1459x, DA1469x, DA1470x, Power Management, Renesas USB Power Delivery Family, ICs for Motor Driver/Actuator Driver, V850, 78K0R, 78K0]
|
Programmer (Unit/SW) | Renesas |
| Code Flash Libraries (Flash Self Programming Libraries) Libraries for the reprogramming of code area flash memory, including EEPROM emulation libraries for the code areas of 78K-family products
|
Self Programming Library (Flash Library) | Renesas |
| Data Flash Libraries Libraries for the reprogramming of data flash memory, including EEPROM emulation libraries for the data areas of RL78-family products
|
Self Programming Library (Flash Library) | Renesas |
| Sensor Software Modules for Renesas MCU Platforms Middleware (FIT module and FSP module) and sample software packages that enable control and data acquisition for Renesas sensor products.
|
Sensor | Renesas |
| Crypto Library Robust encode library to ensure security for all types of system developments
|
Security / Crypto | Renesas |
| RL78 Smart Configurator RL78 Smart Configurator is a utility for combining software in ways that meet your needs. It simplifies the embedding of Renesas drivers in your systems through supports for importing middleware and drivers and configuring pins.
|
Solution Toolkit | Renesas |
| Sound Playback/Compression System [M3S-S2-Tiny] for RL78 Family Sound playback system for RL78 Family
|
Sound / Voice | Renesas |
| e² studio - information for RL78 Family Eclipse-based Renesas integrated development environment (IDE).
|
IDE and Coding Tool | Renesas |
| DALI Master Controller GUI The DALI Master Controller GUI controls an RL78/I1A lighting communication master evaluation board
|
Code Generator | Renesas |
| FAT File System [M3S-TFAT-Tiny] for the RL78 Family FAT file system for RL78 Family
|
File System | Renesas |
| SPI/QSPI Serial Flash Memory, QSPI Serial Phase Change Memory Driver Device Driver for SPI and QSPI Serial Flash Memory and QSPI Serial Phase Change Memory
|
Serial Memory | Renesas |
| IAR Embedded Workbench for Renesas RL78 IAR Embedded Workbench provides extensive support for RL78 devices. IAR Embedded Workbench is a complete set of development tools with leading optimization technology for creating powerful automotive applications.
|
IDE and Coding Tool | IAR Systems |
| Renesas IAR Embedded Workbench Device-Support-Packages Renesas IAR Embedded Workbench Device-Support-Packages include all device-specific files to be used with the Embedded Workbench IDE.
|
IDE and Coding Tool | Renesas |
| QE for OTA: Development Assistance for Cloud QE for OTA is a development assistance tool that enables easy trial of over-the-air (OTA) firmware updates using cloud services. [Plugin for Renesas IDE "e² studio"] [Support MCU/MPU: RX, RL78, RA] [Support clouds service: Amazon Web Services (AWS), Microsoft Azure]
|
Solution Toolkit | Renesas |
|
25 items
|
||
Sample Code
Boards & Kits
RL78/G23-128p Fast Prototyping Board (RL78/G23-128p FPB)
The RL78/G23-128p Fast Prototyping Board comes equipped with an RL78/G23 microcontroller and is an evaluation board specialized for prototype development for a variety...
Featured Documents:
Automatic Liquid Dispenser with Proximity Capacitive Sensing Reference Design
This Automatic Liquid Dispenser with Proximity Capacitive Sensing reference design is for hands-free dispensing of liquids such as soap, hand sanitizer, shampoo, or...
Capacitive Touch Evaluation System for RL78/G23
The RL78/G23 capacitive touch evaluation system makes it easy for users to evaluate touch solutions offered by Renesas. You can start evaluating immediately out of the...
Touch-Free User Interface Reference Design
The 3D Gesture Reference Design is a solution that can detect the position (x, y and z coordinates) of a hand in space using Renesas' capacitive touch solution. The...
Available on Lab on the Cloud
Use our PC-based GUI to instantly start configuring and testing designs in our virtual lab, no physical board needed.
RL78/G23 Inductive Proximity Sensor Shield Solution Board
The RL78/G23 Inductive Proximity Sensor Shield Solution Board is a plug-on expansion board for the RL78/G23 microcontroller 64-pin Fast Prototyping Board (FPB), and is...
Featured Documents:
RL78/G23 Lighting Communication Master Evaluation Board
The RL78/G23 Lighting Communication Master Evaluation Board is a lighting communication master board for controlling evaluation boards for various lighting...
Featured Documents:
RL78/G23 Indoor Air Quality Sensor Demonstration Board
The RL78/G23 Indoor Air Quality Sensor Demonstration Board is a demonstration of the unique and powerful features of the RL78/G23. It enables programming and evaluation...
Featured Documents:
Self-Capacitance Waterproof Button Solution
The Renesas capacitive sensor, CTSU2 can utilize an active shield without any external components. Active shielding is effective in improving water resistance as well...
Intelligent Lighting System Evaluation Kit
This comprehensive lighting control system is designed for building automation. By utilizing the Digital Addressable Lighting Interface (DALI) communication standard to...
Available on Lab on the Cloud
Use our PC-based GUI to instantly start configuring and testing designs in our virtual lab, no physical board needed.
Models
ECAD Models
Schematic symbols, PCB footprints, and 3D CAD models from SamacSys can be found by clicking on products in the Product Options table. If a symbol or model isn't available, it can be requested directly from the website.
Processing table
Program Memory (KB) |
RAM (KB) |
Lead Count (#) |
Temp. Range |
PLP |
Data Flash (KB) |
RTC |
LVD or PVD |
I/O Ports |
Timer |
ADC |
DAC |
UART (#) |
SPI (#) |
I2C (#) |
Human Machine Interface |
Pkg. Type |
Pkg. Dimensions (mm) |
Moisture Sensitivity Level (MSL) |
Price (USD) | 1ku |
Buy / Sample |
|
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Part Number | |||||||||||||||||||||
| 96 | 12 | 30 | -40 to 85°C | 2033 Dec | 8 | Yes | Yes | 26 | 16-bit x 8-ch, 32-bit x 1-ch | 12-bit/10-bit/8-bit x 8-ch | 8-bit x 2-ch | 3 | 3 | 4 | Capacitive Sensing Unit 2ch | LSSOP | 9.85 x 6.1 x 1.4 | 3 | 1.191 | ||
| 96 | 12 | 30 | -40 to 85°C | 2033 Dec | 8 | Yes | Yes | 26 | 16-bit x 8-ch, 32-bit x 1-ch | 12-bit/10-bit/8-bit x 8-ch | 8-bit x 2-ch | 3 | 3 | 4 | Capacitive Sensing Unit 2ch | LSSOP | 9.85 x 6.1 x 1.4 | 3 | |||
| 96 | 12 | 30 | -40 to 105°C | 2033 Dec | 8 | Yes | Yes | 26 | 16-bit x 8-ch, 32-bit x 1-ch | 12-bit/10-bit/8-bit x 8-ch | 8-bit x 2-ch | 3 | 3 | 4 | Capacitive Sensing Unit 2ch | LSSOP | 9.85 x 6.1 x 1.4 | 3 | 1.256 | ||
| 96 | 12 | 30 | -40 to 105°C | 2033 Dec | 8 | Yes | Yes | 26 | 16-bit x 8-ch, 32-bit x 1-ch | 12-bit/10-bit/8-bit x 8-ch | 8-bit x 2-ch | 3 | 3 | 4 | Capacitive Sensing Unit 2ch | LSSOP | 9.85 x 6.1 x 1.4 | 3 | |||
| 128 | 16 | 30 | -40 to 85°C | 2033 Dec | 8 | Yes | Yes | 26 | 16-bit x 8-ch, 32-bit x 1-ch | 12-bit/10-bit/8-bit x 8-ch | 8-bit x 2-ch | 3 | 3 | 4 | Capacitive Sensing Unit 2ch | LSSOP | 9.85 x 6.1 x 1.4 | 3 | |||
| 128 | 16 | 30 | -40 to 85°C | 2033 Dec | 8 | Yes | Yes | 26 | 16-bit x 8-ch, 32-bit x 1-ch | 12-bit/10-bit/8-bit x 8-ch | 8-bit x 2-ch | 3 | 3 | 4 | Capacitive Sensing Unit 2ch | LSSOP | 9.85 x 6.1 x 1.4 | 3 | |||
| 128 | 16 | 30 | -40 to 105°C | 2033 Dec | 8 | Yes | Yes | 26 | 16-bit x 8-ch, 32-bit x 1-ch | 12-bit/10-bit/8-bit x 8-ch | 8-bit x 2-ch | 3 | 3 | 4 | Capacitive Sensing Unit 2ch | LSSOP | 9.85 x 6.1 x 1.4 | 3 | 1.372 | ||
| 128 | 16 | 30 | -40 to 105°C | 2033 Dec | 8 | Yes | Yes | 26 | 16-bit x 8-ch, 32-bit x 1-ch | 12-bit/10-bit/8-bit x 8-ch | 8-bit x 2-ch | 3 | 3 | 4 | Capacitive Sensing Unit 2ch | LSSOP | 9.85 x 6.1 x 1.4 | 3 | |||
| 192 | 20 | 30 | -40 to 85°C | 2033 Dec | 8 | Yes | Yes | 26 | 16-bit x 8-ch, 32-bit x 1-ch | 12-bit/10-bit/8-bit x 8-ch | 8-bit x 2-ch | 3 | 3 | 4 | Capacitive Sensing Unit 6ch | LSSOP | 9.85 x 6.1 x 1.4 | 3 | 1.271 | ||
| 192 | 20 | 30 | -40 to 85°C | 2033 Dec | 8 | Yes | Yes | 26 | 16-bit x 8-ch, 32-bit x 1-ch | 12-bit/10-bit/8-bit x 8-ch | 8-bit x 2-ch | 3 | 3 | 4 | Capacitive Sensing Unit 6ch | LSSOP | 9.85 x 6.1 x 1.4 | 3 | |||
| 192 | 20 | 30 | -40 to 105°C | 2033 Dec | 8 | Yes | Yes | 26 | 16-bit x 8-ch, 32-bit x 1-ch | 12-bit/10-bit/8-bit x 8-ch | 8-bit x 2-ch | 3 | 3 | 4 | Capacitive Sensing Unit 6ch | LSSOP | 9.85 x 6.1 x 1.4 | 3 | 1.712 | ||
| 192 | 20 | 30 | -40 to 105°C | 2033 Dec | 8 | Yes | Yes | 26 | 16-bit x 8-ch, 32-bit x 1-ch | 12-bit/10-bit/8-bit x 8-ch | 8-bit x 2-ch | 3 | 3 | 4 | Capacitive Sensing Unit 6ch | LSSOP | 9.85 x 6.1 x 1.4 | 3 | |||
| 256 | 24 | 30 | -40 to 85°C | 2033 Dec | 8 | Yes | Yes | 26 | 16-bit x 8-ch, 32-bit x 1-ch | 12-bit/10-bit/8-bit x 8-ch | 8-bit x 2-ch | 3 | 3 | 4 | Capacitive Sensing Unit 6ch | LSSOP | 9.85 x 6.1 x 1.4 | 3 | 1.415 | ||
| 256 | 24 | 30 | -40 to 85°C | 2033 Dec | 8 | Yes | Yes | 26 | 16-bit x 8-ch, 32-bit x 1-ch | 12-bit/10-bit/8-bit x 8-ch | 8-bit x 2-ch | 3 | 3 | 4 | Capacitive Sensing Unit 6ch | LSSOP | 9.85 x 6.1 x 1.4 | 3 | |||
| 256 | 24 | 30 | -40 to 105°C | 2033 Dec | 8 | Yes | Yes | 26 | 16-bit x 8-ch, 32-bit x 1-ch | 12-bit/10-bit/8-bit x 8-ch | 8-bit x 2-ch | 3 | 3 | 4 | Capacitive Sensing Unit 6ch | LSSOP | 9.85 x 6.1 x 1.4 | 3 | 1.928 | ||
| 256 | 24 | 30 | -40 to 105°C | 2033 Dec | 8 | Yes | Yes | 26 | 16-bit x 8-ch, 32-bit x 1-ch | 12-bit/10-bit/8-bit x 8-ch | 8-bit x 2-ch | 3 | 3 | 4 | Capacitive Sensing Unit 6ch | LSSOP | 9.85 x 6.1 x 1.4 | 3 | |||
| 96 | 12 | 32 | -40 to 85°C | 2033 Dec | 8 | Yes | Yes | 28 | 16-bit x 8-ch, 32-bit x 1-ch | 12-bit/10-bit/8-bit x 8-ch | 8-bit x 2-ch | 3 | 3 | 4 | Capacitive Sensing Unit 3ch | LQFP | 7 x 7 x 1.7 | 3 | 1 | ||
| 96 | 12 | 32 | -40 to 85°C | 2033 Dec | 8 | Yes | Yes | 28 | 16-bit x 8-ch, 32-bit x 1-ch | 12-bit/10-bit/8-bit x 8-ch | 8-bit x 2-ch | 3 | 3 | 4 | Capacitive Sensing Unit 3ch | LQFP | 7 x 7 x 1.7 | 3 | |||
| 96 | 12 | 32 | -40 to 85°C | 2037 Dec | 8 | Yes | Yes | 28 | 16-bit x 8-ch, 32-bit x 1-ch | 12-bit/10-bit/8-bit x 8-ch | 8-bit x 2-ch | 3 | 3 | 4 | Capacitive Sensing Unit 3ch | HWQFN | 5 x 5 x 0.8 | 3 | |||
| 96 | 12 | 32 | -40 to 85°C | 2037 Dec | 8 | Yes | Yes | 28 | 16-bit x 8-ch, 32-bit x 1-ch | 12-bit/10-bit/8-bit x 8-ch | 8-bit x 2-ch | 3 | 3 | 4 | Capacitive Sensing Unit 3ch | HWQFN | 5 x 5 x 0.8 | 3 | |||
| 96 | 12 | 32 | -40 to 105°C | 2033 Dec | 8 | Yes | Yes | 28 | 16-bit x 8-ch, 32-bit x 1-ch | 12-bit/10-bit/8-bit x 8-ch | 8-bit x 2-ch | 3 | 3 | 4 | Capacitive Sensing Unit 3ch | LQFP | 7 x 7 x 1.7 | 3 | 1.073 | ||
| 96 | 12 | 32 | -40 to 105°C | 2033 Dec | 8 | Yes | Yes | 28 | 16-bit x 8-ch, 32-bit x 1-ch | 12-bit/10-bit/8-bit x 8-ch | 8-bit x 2-ch | 3 | 3 | 4 | Capacitive Sensing Unit 3ch | LQFP | 7 x 7 x 1.7 | 3 | |||
| 96 | 12 | 32 | -40 to 105°C | 2037 Dec | 8 | Yes | Yes | 28 | 16-bit x 8-ch, 32-bit x 1-ch | 12-bit/10-bit/8-bit x 8-ch | 8-bit x 2-ch | 3 | 3 | 4 | Capacitive Sensing Unit 3ch | HWQFN | 5 x 5 x 0.8 | 3 | |||
| 96 | 12 | 32 | -40 to 105°C | 2037 Dec | 8 | Yes | Yes | 28 | 16-bit x 8-ch, 32-bit x 1-ch | 12-bit/10-bit/8-bit x 8-ch | 8-bit x 2-ch | 3 | 3 | 4 | Capacitive Sensing Unit 3ch | HWQFN | 5 x 5 x 0.8 | 3 | |||
| 128 | 16 | 32 | -40 to 85°C | 2033 Dec | 8 | Yes | Yes | 28 | 16-bit x 8-ch, 32-bit x 1-ch | 12-bit/10-bit/8-bit x 8-ch | 8-bit x 2-ch | 3 | 3 | 4 | Capacitive Sensing Unit 3ch | LQFP | 7 x 7 x 1.7 | 3 | 1.087 | ||
| 128 | 16 | 32 | -40 to 85°C | 2033 Dec | 8 | Yes | Yes | 28 | 16-bit x 8-ch, 32-bit x 1-ch | 12-bit/10-bit/8-bit x 8-ch | 8-bit x 2-ch | 3 | 3 | 4 | Capacitive Sensing Unit 3ch | LQFP | 7 x 7 x 1.7 | 3 | |||
| 128 | 16 | 32 | -40 to 85°C | 2037 Dec | 8 | Yes | Yes | 28 | 16-bit x 8-ch, 32-bit x 1-ch | 12-bit/10-bit/8-bit x 8-ch | 8-bit x 2-ch | 3 | 3 | 4 | Capacitive Sensing Unit 3ch | HWQFN | 5 x 5 x 0.8 | 3 | |||
| 128 | 16 | 32 | -40 to 85°C | 2037 Dec | 8 | Yes | Yes | 28 | 16-bit x 8-ch, 32-bit x 1-ch | 12-bit/10-bit/8-bit x 8-ch | 8-bit x 2-ch | 3 | 3 | 4 | Capacitive Sensing Unit 3ch | HWQFN | 5 x 5 x 0.8 | 3 | |||
| 128 | 16 | 32 | -40 to 105°C | 2033 Dec | 8 | Yes | Yes | 28 | 16-bit x 8-ch, 32-bit x 1-ch | 12-bit/10-bit/8-bit x 8-ch | 8-bit x 2-ch | 3 | 3 | 4 | Capacitive Sensing Unit 3ch | LQFP | 7 x 7 x 1.7 | 3 | 1.372 | ||
| 128 | 16 | 32 | -40 to 105°C | 2033 Dec | 8 | Yes | Yes | 28 | 16-bit x 8-ch, 32-bit x 1-ch | 12-bit/10-bit/8-bit x 8-ch | 8-bit x 2-ch | 3 | 3 | 4 | Capacitive Sensing Unit 3ch | LQFP | 7 x 7 x 1.7 | 3 | |||
| 128 | 16 | 32 | -40 to 105°C | 2037 Dec | 8 | Yes | Yes | 28 | 16-bit x 8-ch, 32-bit x 1-ch | 12-bit/10-bit/8-bit x 8-ch | 8-bit x 2-ch | 3 | 3 | 4 | Capacitive Sensing Unit 3ch | HWQFN | 5 x 5 x 0.8 | 3 | |||
| 128 | 16 | 32 | -40 to 105°C | 2037 Dec | 8 | Yes | Yes | 28 | 16-bit x 8-ch, 32-bit x 1-ch | 12-bit/10-bit/8-bit x 8-ch | 8-bit x 2-ch | 3 | 3 | 4 | Capacitive Sensing Unit 3ch | HWQFN | 5 x 5 x 0.8 | 3 | |||
| 192 | 20 | 32 | -40 to 85°C | 2033 Dec | 8 | Yes | Yes | 28 | 16-bit x 8-ch, 32-bit x 1-ch | 12-bit/10-bit/8-bit x 8-ch | 8-bit x 2-ch | 3 | 3 | 4 | Capacitive Sensing Unit 7ch | LQFP | 7 x 7 x 1.7 | 3 | 1.565 | ||
| 192 | 20 | 32 | -40 to 85°C | 2033 Dec | 8 | Yes | Yes | 28 | 16-bit x 8-ch, 32-bit x 1-ch | 12-bit/10-bit/8-bit x 8-ch | 8-bit x 2-ch | 3 | 3 | 4 | Capacitive Sensing Unit 7ch | LQFP | 7 x 7 x 1.7 | 3 | |||
| 192 | 20 | 32 | -40 to 105°C | 2033 Dec | 8 | Yes | Yes | 28 | 16-bit x 8-ch, 32-bit x 1-ch | 12-bit/10-bit/8-bit x 8-ch | 8-bit x 2-ch | 3 | 3 | 4 | Capacitive Sensing Unit 7ch | LQFP | 7 x 7 x 1.7 | 3 | 1.654 | ||
| 192 | 20 | 32 | -40 to 105°C | 2033 Dec | 8 | Yes | Yes | 28 | 16-bit x 8-ch, 32-bit x 1-ch | 12-bit/10-bit/8-bit x 8-ch | 8-bit x 2-ch | 3 | 3 | 4 | Capacitive Sensing Unit 7ch | LQFP | 7 x 7 x 1.7 | 3 | |||
| 256 | 24 | 32 | -40 to 85°C | 2033 Dec | 8 | Yes | Yes | 28 | 16-bit x 8-ch, 32-bit x 1-ch | 12-bit/10-bit/8-bit x 8-ch | 8-bit x 2-ch | 3 | 3 | 4 | Capacitive Sensing Unit 7ch | LQFP | 7 x 7 x 1.7 | 3 | 1.743 | ||
| 256 | 24 | 32 | -40 to 85°C | 2033 Dec | 8 | Yes | Yes | 28 | 16-bit x 8-ch, 32-bit x 1-ch | 12-bit/10-bit/8-bit x 8-ch | 8-bit x 2-ch | 3 | 3 | 4 | Capacitive Sensing Unit 7ch | LQFP | 7 x 7 x 1.7 | 3 | |||
| 256 | 24 | 32 | -40 to 105°C | 2033 Dec | 8 | Yes | Yes | 28 | 16-bit x 8-ch, 32-bit x 1-ch | 12-bit/10-bit/8-bit x 8-ch | 8-bit x 2-ch | 3 | 3 | 4 | Capacitive Sensing Unit 7ch | LQFP | 7 x 7 x 1.7 | 3 | |||
| 256 | 24 | 32 | -40 to 105°C | 2033 Dec | 8 | Yes | Yes | 28 | 16-bit x 8-ch, 32-bit x 1-ch | 12-bit/10-bit/8-bit x 8-ch | 8-bit x 2-ch | 3 | 3 | 4 | Capacitive Sensing Unit 7ch | LQFP | 7 x 7 x 1.7 | 3 | |||
| 96 | 12 | 40 | -40 to 85°C | 2037 Dec | 8 | Yes | Yes | 36 | 16-bit x 8-ch, 32-bit x 1-ch | 12-bit/10-bit/8-bit x 9-ch | 8-bit x 2-ch | 4 | 4 | 5 | Capacitive Sensing Unit 6ch | HWQFN | 6 x 6 x 0.8 | 3 | |||
| 96 | 12 | 40 | -40 to 85°C | 2037 Dec | 8 | Yes | Yes | 36 | 16-bit x 8-ch, 32-bit x 1-ch | 12-bit/10-bit/8-bit x 9-ch | 8-bit x 2-ch | 4 | 4 | 5 | Capacitive Sensing Unit 6ch | HWQFN | 6 x 6 x 0.8 | 3 | 1.327 | ||
| 96 | 12 | 40 | -40 to 105°C | 2037 Dec | 8 | Yes | Yes | 36 | 16-bit x 8-ch, 32-bit x 1-ch | 12-bit/10-bit/8-bit x 9-ch | 8-bit x 2-ch | 4 | 4 | 5 | Capacitive Sensing Unit 6ch | HWQFN | 6 x 6 x 0.8 | 3 | |||
| 96 | 12 | 40 | -40 to 105°C | 2037 Dec | 8 | Yes | Yes | 36 | 16-bit x 8-ch, 32-bit x 1-ch | 12-bit/10-bit/8-bit x 9-ch | 8-bit x 2-ch | 4 | 4 | 5 | Capacitive Sensing Unit 6ch | HWQFN | 6 x 6 x 0.8 | 3 | 1.417 | ||
| 128 | 16 | 40 | -40 to 85°C | 2037 Dec | 8 | Yes | Yes | 36 | 16-bit x 8-ch, 32-bit x 1-ch | 12-bit/10-bit/8-bit x 9-ch | 8-bit x 2-ch | 4 | 4 | 5 | Capacitive Sensing Unit 6ch | HWQFN | 6 x 6 x 0.8 | 3 | |||
| 128 | 16 | 40 | -40 to 85°C | 2037 Dec | 8 | Yes | Yes | 36 | 16-bit x 8-ch, 32-bit x 1-ch | 12-bit/10-bit/8-bit x 9-ch | 8-bit x 2-ch | 4 | 4 | 5 | Capacitive Sensing Unit 6ch | HWQFN | 6 x 6 x 0.8 | 3 | |||
| 128 | 16 | 40 | -40 to 105°C | 2037 Dec | 8 | Yes | Yes | 36 | 16-bit x 8-ch, 32-bit x 1-ch | 12-bit/10-bit/8-bit x 9-ch | 8-bit x 2-ch | 4 | 4 | 5 | Capacitive Sensing Unit 6ch | HWQFN | 6 x 6 x 0.8 | 3 | |||
| 128 | 16 | 40 | -40 to 105°C | 2037 Dec | 8 | Yes | Yes | 36 | 16-bit x 8-ch, 32-bit x 1-ch | 12-bit/10-bit/8-bit x 9-ch | 8-bit x 2-ch | 4 | 4 | 5 | Capacitive Sensing Unit 6ch | HWQFN | 6 x 6 x 0.8 | 3 | 1.536 | ||
| 96 | 12 | 44 | -40 to 85°C | 2033 Dec | 8 | Yes | Yes | 40 | 16-bit x 8-ch, 32-bit x 1-ch | 12-bit/10-bit/8-bit x 10-ch | 8-bit x 2-ch | 5 | 4 | 6 | Capacitive Sensing Unit 6ch | LQFP | 10 x 10 x 1.6 | 3 | |||
| 96 | 12 | 44 | -40 to 85°C | 2033 Dec | 8 | Yes | Yes | 40 | 16-bit x 8-ch, 32-bit x 1-ch | 12-bit/10-bit/8-bit x 10-ch | 8-bit x 2-ch | 5 | 4 | 6 | Capacitive Sensing Unit 6ch | LQFP | 10 x 10 x 1.6 | 3 | 1.476 |
Tips for Using This Parametric Table:
- Hide Filters button in header: Collapse or expands filters
- Column sort buttons in header: Sort Column alphabetically / numerically descending or ascending
- Reset button in header: Reset all filters to the page default
- Full Screen button in header: Expand the table to full screen view (user must close out of full screen before they can interact with rest of page)
- Export button in header: Export the filtered results of the table to an Excel document
- Filter parts search bar in header: Type to filter table results by part number
- Hide column button in column headers: Select to hide columns in table
- AND / OR toggle switches in header: Toggles the logic of this particular filter to be “AND” or “OR” logic for filtering results
- Multiselect checkboxes at beginning of each row in table: Select these checkboxes to compare products against each other
- Document icon next to product name in row: View the featured document for this product
- Chip icon next to the right of the document icon in row: View the block diagram for this product
- Cart icon to the right of the chip icon: Indicates that samples are available for this product
Videos & Training
Rl78 Arduino Tutorial - Rl78 Arduino Introduction of Sample Sketch Using Arduino Library
This video introduces how to display data from the HS3001 sensor on the serial monitor of the Arduino IDE using RL78/G23-64p Fast Prototyping Board and HS3001.
Chapter's Title
00:00 Opening
01:08 Board Connections
01:23 Setup of Board Manager
02:14 Sample sketch operation
03:23 Ending
